Newland FM430 Fixed Mount Barcode Scanner (1D / 2D)

Newland FM430 is a fixed-mount barcode scanner for kiosks and self-service systems. Supports fast and accurate decoding of both 1D and 2D barcodes. Equipped with a CMOS 1280 × 800 sensor and LED illumination. Features a highly visible crosshair laser aimer, clear even in bright light. Connectivity options include RS-232 and USB for flexible integration. Rugged IP54 design ensures dustproof, waterproof, and 1.5 m drop resistance. IR/Light Trigger enables automatic barcode detection for higher throughput. Ideal for ticketing machines, check-in systems, access control, and gaming applications.

Key Specifications

• Decode Capability: 1D & 2D (PDF417, QR Code, Data Matrix, Aztec, etc.)
• Image Sensor: CMOS 1280 × 800
• Illumination: White LED
• Resolution: ≥3 mil
• Depth of Field:
  • EAN‑13 (13 mil): 55–360 mm
  • Code 39 (20 mil): 40–210 mm
  • QR Code (20 mil): 50–170 mm
• Scan Angles: Roll 360°, Pitch ±55°, Skew ±55°
• Scan Modes: Sense, Continuous, Level, Pulse
• Aiming: 650 nm laser diode or 518 nm green LED
• Dimensions: 41.5 × 49.5 × 24.3 mm
• Weight: 56 g
• Interfaces: RS‑232, USB
• Operating Voltage: 5 VDC ±5%
• Notification: Beeper + LED indicator
• Sealing: IP54, 1.5 m drop resistance, ESD ±14kV (air), ±8kV (direct)

Special Features

• 1.5 m Drop Resistance: Withstands multiple drops on concrete.
• Automatic Exposure Control (AEC): Adjusts lighting automatically.
• Highly Visible Laser Aimer: Crosshair pattern visible even in bright sunlight.
• IP54 Housing: Dustproof and moisture‑resistant.
• IR/Light Trigger: Activates scanning automatically for higher throughput.
• Snappy Barcode Capture: 5th‑generation UIMG® technology reads printed and on‑screen barcodes quickly.

Usage Summary

NLS-FM430 is ideal for kiosks, vending machines, gaming systems, access control, and ticket validation. With IP54 durability, advanced scanning technology, and automatic triggers, it ensures fast, accurate, and reliable barcode reading in demanding environments.
