Hikvision DS-D60E-B Digital Signage Box 4K UHD

Hikvision DS-D60E-B Digital Signage Box 4K UHD

Hikvision DS-D60E-B is a digital signage box supporting multiple media formats. It can display images, audio, video, PDF, webpages, and streaming content flexibly. Centralized management enables convenient remote control of multiple displays. Flexible scheduling allows daily, weekly, or customized playback settings. Enhanced security features include multi-level review and encrypted data protection. Ideal for businesses requiring efficient and secure digital signage management.

Specifications

• Operating System: Android 8.1.0
• CPU: Cortex-A17, Quad-core, 1.6 GHz
• Memory: RAM 2 GB, Storage 16 GB (eMMC)
• Interfaces: Audio In ×1, Audio Out ×1, HDMI Out ×1, LAN ×1, Wi-Fi, USB 2.0 ×2, Bluetooth 4.0
• Supported Resolutions:
  • 1920×1080 @30/50/60 Hz
  • 1280×720 @30/50/60 Hz
  • 3840×2160 @30/50/60 Hz
• Power Supply: 12 VAC, 2 A, Standby ≤ 1 W
• Operating Environment: Temperature 0–40°C, Humidity 10–90%
• Dimensions/Weight: 145×145×31.89 mm, Net weight 0.6 kg
• Package Contents: Power adaptor ×1, Remote control ×1

Special Features

• Multi-format Media Support: Displays images, audio, video, PDF, streaming, webpages, live video, and third-party data
• Flexible Scheduling: Program playback by day, week, or custom settings
• Centralized Management: Remote control of multiple displays, including power on/off, brightness, volume, and screen preview
• Organizational Management: 5-level hierarchy for media, programs, terminals, and users
• User Permissions: Multi-level access control for enhanced security
• Security Safeguards: Triple-level review before publishing, screensaver protection, and encrypted data to prevent tampering
• Remote Control (433 MHz): Operates from any direction for convenient management

Usage Summary

The Hikvision DS-D60E-B is a digital signage box designed for flexible content management, centralized control, and strong security features. It is ideal for businesses that need to manage multiple displays, schedule diverse media formats, and ensure reliable, secure content delivery.

Datasheet : Hikvision DS-D60E-B Digital Signage Box
