Axicon 7100S Barcode Verifiers High Speed Large Linear

ISO/IEC verification with ANSI option, traditional verification, symbology auto-discrimination, automatic variable aperture, scan saving and loading, static reflectance meter, display of x-dimension and magnification, individual bar and space dimensional analysis.  Product look-up option and other software plugins are available to validate data content of codes such as PZN, CIP, ISBN, ISSN.

Specifications

Hardware
A CCD imager-based linear barcode verifier, designed to be ISO/IEC compliant. Aperture automatically switchable between aperture reference numbers 08, 10 and 20.  Scan width 200mm or 7.8″ (including quiet zones). Wavelength of light 660 nm.  Weight: 1kg. Size: 240 x 148 x 170 mm.

Connectivity
USB-2

System Requirements
Designed to function with any PC running any currently supported version of Microsoft Windows.

The verifier is supplied as the verifier read-head, its data cable, a quick start guide, a calibration card and compliance certificates in a protective carry case.

Datasheet : Axicon 7100S Barcode Verifiers High Speed Large Linear
