HID Omnikey 5427 CK (GEN 2) Smart Card Reader


The HID OMNIKEY 5427 CK Card Reader is a contactless card reader integrated with standard CCID technology, secure, easy to use.


เครื่องอ่านบัตร HID Omnikey 5427 CK  (GEN 2) Card Reader


เครื่องอ่านบัตร HID Omnikey 5427 CK  (GEN 2) Card Reader


HID Omnikey 5427 CK (GEN 2) Smart Card Reader

The OMNIKEY® 5427CK Reader supports both low and high frequency credentials and can be operated using Bluetooth and NFC allowing customers to leverage their mobile access credentials to access computer, network or cloud by using their mobile phone. It leverages Secure Identity Object™ (SIO) to offer solutions that are secure, tech-independent and flexible, thus making it ideal for mixed technology environments.


One Reader, Two Choices
  • OMNIKEY 5427CK Standard Reader: Programmable multifrequency reader that supports a broad variety of low (125 kHz) and high (13.56 MHz) frequency platforms that you can use in a variety of applications
  • OMNIKEY 5427CK With Bluetooth Interface: Mobile access on the desktop that allows you to access your computers, networks or cloud simply by using your mobile phone


Key Benefits

  • Dual Frequency: Simultaneously supports low and high frequency credentials, including Seos®, HID Prox®, iCLASS SE®, MIFARE® Classic®, MIFARE Plus®, MIFARE Ultralight® and MIFARE DESFire® EV1, EV2 as well as NFC
  • Mobile access: A Bluetooth interface is all that is required for the reader to access a computer, network, data or cloud
  • Multilayered security: Additional protection for identity data — more than what a regular card offers — via Seos and iCLASS SE platforms
  • Keyboard wedge functionality: Data is retrieved from the card and directly fed into an application
  • Ease of use: Be it for PC log-in or using key strokes via the keyboard wedge



Technical data

2.79" x 3.66" x 0.63" (71 mm x 93 mm x 16 mm)
Weight Reader only
Approx.3.53 oz (100g)
Host Interface
USB 2.0 CCID1 (also compliant with USB 1.1)
Transmission Speed
12 Mbps (USB 2.0 full speed)
ISO 7816 & EMV2 2000 Level 1
Cards / Protocols
High Frequency
iCLASS®, iCLASS® SE/SR, iCLASS® Seos MIFARE ™ Classic 1K / 4K, Ultra Light, Ultra Light C,
Plus, MIFARE™ DESFIRE™ 0.6, MIFARE™ DESFIRE™ EV1, MIFARE SE, DESFire EV1 SE, T=CL, ISO 14443 A with up to 848 kbps transmission rate (depending on card1), ISO 15693 with up to 26 kbps transmission rate (depending on card)

The following credentials can be handled autonomously: iCLASS®, iCLASS® SE/SR, iCLASS® Seos MIFARE SE, DESFire EV1 SE MIFARE™ Classic 1K / 4K, Ultra Light, Ultra Light C, Plus (Security Lvl 1) , MIFARE™ DESFIRE™ 0.6, MIFARE™ DESFIRE™ EV1 (MAC / DES/3DES /3K3DES / AES)
Cards / Protocols
Low Frequency HID PROX®, HID Indala® Prox, EM Prox®
PC / SC Driver Support
Windows® 2000 / XP (32 bit), 2003 Server, 2008 Server, Windows® CE 5.0 / CE.NET / CE 6.0 (depending on hardware), Windows® XP (64 bit), Windows® Vista (32 bit / 64 bit), Windows 7 (32 bit / 64 bit), Linux®, Mac® OS X (Power PC / Intel)
Cover Black / Body light grey
Meantime Between Failure (MTBF)500,000 hours




Datasheet : HID Omnikey 5427 CK (GEN 2) Card Reader
