Horion M5A Series Smart Interactive Flat Panel
Attribute:
Horion interactive lat panel brings a new way of interaction and display. 4K Screen Mirroring/Reverse Touch Control/Quad Split Screen
Categories : Interactive Touch Screen Bord , Digital Media , Digital Media Site Reference ,
Share
- For meetings, classrooms, hybrid and remote
- Sharp picture at 4K level (3840 x 2160)
- Android 8.0 operating system
- The IR touch screen writes smoothly and you can use your palm to erase what is written.
- 13MP HD Digital Camera
- Intelligent pen with a microscopic touch point at the tip of the pen.
- Supports wireless screen connection
- There is a noise-filtering microphone ready for teleconferencing.
- There is after-sales service and teaching detailed usage techniques.
- Take meeting notes, save them, and come back and edit them next time.
- Open various document files and save files to Google Drive.
- Suitable for small-medium rooms 15-35 Sqm. 10-15 people.
- For meetings, classrooms, hybrid and remote
- Sharp picture at 4K level (3840 x 2160)
- Android 8.0 operating system
- The IR touch screen writes smoothly and you can use your palm to erase what is written.
- 13MP HD Digital Camera
- Intelligent pen with a microscopic touch point at the tip of the pen.
- Supports wireless screen connection
- There is a noise-filtering microphone ready for teleconferencing.
- There is after-sales service and teaching detailed usage techniques.
- Take meeting notes, save them, and come back and edit them next time.
- Open various document files and save files to Google Drive.
- Suitable for medium sized rooms 40 Sqm. 15-30 people.
- For meetings, classrooms, hybrid and remote
- Sharp picture at 4K level (3840 x 2160)
- Android 8.0 operating system
- The IR touch screen writes smoothly and you can use your palm to erase what is written.
- 13MP HD Digital Camera
- Intelligent pen with a microscopic touch point at the tip of the pen.
- Supports wireless screen connection
- There is a noise-filtering microphone ready for teleconferencing.
- There is after-sales service and teaching detailed usage techniques.
- Take meeting notes, save them, and come back and edit them next time.
- Open various document files and save files to Google Drive.
- Suitable for large rooms 50 Sqm. or more, 30-35 people.
| Model | 65M5A | 75M5A | 86M5A |
| Dimension | 65" | 75" | 86" |
| Display | |||
| Backlight Type | D-LED | D-LED | D-LED |
| Resolution | 3840*2160(UHD) | 3840*2160(UHD) | 3840*2160(UHD) |
| Brightness | 350cd/m2 | 400cd/m2 | 400cd/m2 |
| Contrast Ratio | 1200:1 | 1200:1 | 1200:1 |
| Response Time | 8ms | 8ms | 8ms |
| Pixel Pitch | 0.372mm*0.372mm | 0.4296mm*0.4296mm | 0.4935mm*0.4935mm |
| Refreshing Frequency | 60Hz | 60Hz | 60Hz |
| Viewing Angle | 178°(H)/178°(V) | 178°(H)/178°(V) | 178°(H)/178°(V) |
| saturation(x% Ntsc) | 72% | 72% | 72% |
| visable Area | 1428.48mm*803.52mm | 1649.66mm*927.936mm | 1895.04mm*1065.96mm |
| Chromaticly | 1.07B(10bit) | 1.07B(10bit) | 1.07B(10bit) |
| Life Time | 30,000 hrs | 30,000 hrs | 30,000 hrs |
| I5,OPS(optional) | Intel ® CoreTMI5 8400 processor, RAM:8GB+SSD:128GB | ||
