Jolimark DP760E Serial Dot Matrix Printer 24-Pin

Jolimark DP760E Printer with 1 year On-Site Service

Jolimark DP760E Serial Dot Matrix Printer

A mid-size printer capable of handling high-volume print jobs, featuring printhead cooling technology unmatched by other printers in its class.

Jolimark DP760E Features :

• 24-pin, long-carriage printer
• Print speed: 400 characters per second
• High-volume printhead with a direct thermal cooling system
• 256KB of printer memory
• Ethernet, parallel, and USB connectivity

Jolimark DP760E Serial Dot Matrix Printer

The Jolimark DP760 is a 24-pin dot matrix printer designed for various document types such as continuous forms, passbooks, and official papers. It delivers print speeds up to 400 characters per second and features automatic edge and skew detection for precise alignment. Supporting up to 7-layer carbon copies, it adjusts paper thickness automatically to maintain print quality. Built for durability and long-term use, the DP760 is ideal for large organizations and offers versatile connectivity including USB, Parallel, Ethernet, Wi-Fi, and Bluetooth.

Technical Specifications

• Printing Type: 24-pin impact dot matrix
• Print Direction: Bi-directional with logic seeking
• Print Speed (10CPI):
• Super High Speed: 400 cps
• High Speed: 300 cps
• Normal: 150 cps
• Print Width: 136 columns / 345.44 mm
• Print Head Life: Over 500 million dots per pin
• Buffer Memory: 256 KB
• MTBF: 30,000 hours
• Noise Level: <55 dB(A) per ISO7779
• Dimensions: 580 × 246 × 210 mm
• Weight: Approx. 8.15 kg
• Power Supply: 220V AC, 50–60Hz
• Supported OS: Windows XP, 7, 8, Server 2008

Paper Handling

• Paper Types:
  • Cut sheets: front in–out or front in–rear out
  • Continuous paper (tractor feed): rear in–front out
• Paper Width:
  • Cut sheets: 75–440 mm
  • Tractor feed: 101.6–430 mm
• Max Paper Thickness: 2.0 mm
• Copy Capability: 1 original + 6 copies

Special Features

• Font Support: Orator, Roman, Sans Serif, Courier, OCR-A, OCR-B
• Barcode Support: EAN-13, Code 39, Code 128, and more
• Line Spacing Options: 1/6", 1/8", and fine increments up to 1/360"
• Connectivity Options:
  • USB 2.0 + Parallel (UP model)
  • USB + Parallel + Ethernet (UPE model)
  • USB + Parallel + Bluetooth (UPB model)
  • USB + Serial (US model)
  • USB + Parallel + Wi-Fi (UPW model)
• Smart Features:
  • Automatic paper edge detection
  • Skew detection
  • Optional black mark detection
  • Pin failure compensation
  • Automatic pin switching
  • Auto adjustment for paper thickness and copy count
  • Online parameter configuration

Datasheet : Jolimark DP760E Serial Dot Matrix Printer

Jolimark DP760E, 400 CPS Serial Dot Matrix Printer (USB, Parallel, Ethernet)
